Note: This is a shell-integrated cartridge, so it is exclusively for universal tonearms.

The fixed part of Amane's power generating mechanism uses a special damping alloy that has the highest vibration and sound absorption ability, achieving sound quality with clearer sound contours. The exterior material is precision machined from solid aluminum, hand buffed and finished with metallic alumite. The stylus tip is a microridge type solid diamond, and the magnet is a neodymium magnet. The cantilever is made of boron, which is advantageous for vibration transmission. The connector and contacts are gold plated, and the internal wiring uses 6N leads. It was developed with the idea of reproducing dynamic and rich sounds and making listening to recorded music more enjoyable. IKEDA Amane has been carefully adjusted and assembled over time to bring out the charm of the music itself.

specification

IKEDA AMANE (Zhou) - Specifications -

Power generation method: Moving coil type

Output voltage 0.3mVrms (1KHz 35.4mm/sec at 45°peak)

Appropriate stylus pressure range: 1.8-2.2g

Playback frequency range: 10~45.000Hz

Coil impedance 2.5Ω (1kHz)

Channel separation 30dB or more (1kHz)

Channel balance 0.5dB or less (1kHz)

Compliance 7×10-6cm/dyne

Stylus tip micro ridge type solid diamond

Cantilever made of boron

Mass: approx. 35g

Needle replacement, power generation unit replacement*
