■Wireless control/12 channel digital mixer

Ui Series mixers are compatible with iOS, Android, Windows, Mac OS, and Linux devices and can be controlled from up to 10 control devices simultaneously. It also has built-in dbx, DigiTech, and Lexicon signal processors from HARMAN, including dbx AFS2 and DigiTech Amp Modeling. Both the Ui12 and Ui16 models feature recallable, remote-controllable mic gain and phantom power, 4-band parametric EQ, high-pass filter, compressor, de-esser, and noise gate on the input channels.

It features a 31-band graphic EQ, noise gate, and compressor on all outputs, a real-time frequency analyzer (RTA) on input and output, and three dedicated Lexicon FX buses (reverb, delay, chorus). It also includes mixer controls such as subgroups, mute groups, and view groups. It also has a show/snapshot function by calling channels, and a security lockout function allows you to set it so that you can only access the functions you need. . Additionally, both models are equipped with independent network interfaces that allow simultaneous control via Wi-Fi and Ethernet, and feature a robust chassis suitable for live use.

The Ui12 features 4 XLR phone combo mic/line inputs, 4 XLR mic inputs, 2 channels of Hi-Z/instrument inputs, and stereo RCA line inputs. It also features a 2-channel USB media player, 2 balanced XLR aux outputs, 2 headphone outputs with level control, a balanced stereo XLR phone output and a main phone output. 2-channel USB audio playback supports MP3, WAV, and AIFF formats.

<Main functions>

■Tablet/PC/smartphone controlled digital mixer

■Equipped with Wi-Fi

■Compatible with iOS, Android, Windows, Mac OS, Linux devices

■Can be controlled simultaneously from up to 10 control devices (tablet, mobile phone, PC)

■Legendary signal processing from dbx, Digitech, and Lexicon provided by Harman

Mic preamp with callable presets and remote control

■4-band parametric EQ, high-pass filter, compressor, de-esser, noise gate (input channel)

■Equipped with 31-band graphic EQ, noise gate, and compressor on all outputs

■Equipped with real-time frequency analyzer (RTA) for input and output

■Three dedicated Lexicon FX effect processors. reverb, delay, chorus

■Subgroups, mute groups, view groups, and other mixer controls

■Security Lockout possible show/snapshot recall, channel safe

■2-channel USB audio playback and recording

■Password-protected access restriction system

■Sync ID (synchronize multiple browser windows for each channel)

■Input/output terminal

Combo jack: 4

XLR input: 4

Stereo line input (RCA): 1

MIX L/R line output (XLR/TRS): 1 each

AUX line output (XLR): 2 (2 lines can be added by switching the headphone terminal)

Headphone terminal: 2

USB: 3

Ethernet (RJ45): 1

Foot switch (standard phone)

■Bus

MIX L/R bus: 1 each

AUX bus: 2 (2 lines can be added by switching the headphone jack)

FX bus: 3

■AD-DA conversion: 24bit, 48kHz

■Internal processing: 32bit floating point calculation

■Latency: 1.8ms (mic/line input to line output)

■Power supply: DC18V (1.5A), AC adapter (AC100V, 50/60Hz)

■Size (WxHxD): 321 x 177 x 77mm (excluding protrusions)

■Weight: 2.3kg

*Not compatible with rack mount
